Product details
Legrand - Outside corner for direct molding chute Mosaic 50x80mm - white
Improved aesthetics (cut overlap)
Variable interior angle from 85 to 120 degrees
Respect of the protection index.

Mosaic program ducts with direct clip-on

Product details
Legrand - Flat angle 90DEG for Mosaic direct clipping chute 50x80mm - white
Improved aesthetics (cut overlap)
90 degree flat angle
Respect of the protection index.

Mosaic program ducts with direct clip-on

Technical characteristics of the product
Cover plate
Installation height: 0 mm
Bore diameter (opening): 0 mm
Installation width: 0 mm
Suitable for concealed installation: No
Label holder: No
Suitable for a floor box: No
Adapted to a light channel: Yes
Suitable for integrated installation: No
Ral number (equivalent): 9003
Transparent: No
With protective flap: No
Material quality: Other
Surface finish: Glossy
Protection index (ip): Ip40
Type of fastening: Other
Number of units, horizontal: 1
Number of units, vertical: 1
Number of units: 1
Installation direction: Horizontal
Surface treatment: Untreated
Halogen-free: Yes
White colour
Material: plastic
Number of horizontal modules (modular construction): 4
Impact protection index (ik): Ik07

Specification:

Interface Connections: (2) RJ45 Female Connectors
ESD/EMP Protection: Absorbing Transient Current with Response to Surge Voltage from 100V/s to 1kV/μs
DC Spark-Over Voltage: 90V @ 100V/s
Maximum Impulse Spark-over Voltage: 700V @ 1kV/μs
Discharge Current: 10kA+
Maximum Insulation Resistance: 1G ohm @ 50V
Maximum Capacitance: 1.0 pF @ 1 MHz
Data Line Protection: RJ45 10/100/1000 Ethernet
IEEE 802.3af PoE Support: Yes
Shock and Vibration Certification: ETSI300-019-1.4 Standard

19 inches. Black.

Plastic ring grommet, 1U, vertical, 19 inches. Black color.

Short RJ-45 CAT socket. 5th armored
For single-strand or multi-strand cable!

- Category: CAT. 5th STP
- 360 degree shielding
- For single-strand or multi-strand cable: AWG22 to AWG26
- Standard: ANSI / TIA 568C.2, ISO / IEC 11801
- Format: keystone
- Connection: block 110 or Krone
- Contacts: 50 microns OR
- Compatible with high density panels
- Certification: ETL, UL
- Dimensions: L18 x H22 x D30 mm

Product details
Legrand - Outside corner for Mosaic direct clipping chute 50x105mm - white
Improved aesthetics (cut overlap)
Variable interior angle from 85 to 120 degrees
Respect of the protection index.

Mosaic program ducts with direct clip-on
