GENERAL ELECTRIC CABLE FTP CAT6 4P RIGID SECTION 1.5 500M

Cable type: Electric

Cable category: Rigid

Use: exterior / interior

Cable section: 2.5 mm²

Length: 500 m

Advantages of the product: Simple to install Facilitates the association of the male plug to the female plug Main Features : Installs on a power outlet Product Features : Coding Attaches directly to the 2P + T plug of the device intended to be connected to the polarized socket

Product details
Legrand - 2P + E socket with Mosaic coding 2 modules with connection by screw terminals - red Terminal marking for easy wiring
Franco-Belgian standard, 16A, 230V

Mosaic program

Main Features :
Product Line: OptiLine 45
Wiring installation system: Junction
Product / Component Type: Duct System Installation
Sharing material: Plastic
Cross section of sharing: 75 x 55 mm
Additional features:
Compartment separation: 1 compartment
Color shade: White
Fastening method: By screw
Dimension of the front opening: 45 mm
Material: PVC (polyvinyl chloride)
Manufacturer Info: 24 m
Length: 2000 mm
Height: 75 mm
Width: 55 mm

Main Features :

     Product line: OptiLine
     Cabling installation system: Junction
     Type of product or component: Mini molding
     Product compatibility: Mini molding

Additional features:

     Partition material: Plastic
     Separation of compartments: 3 compartments
     Color tint: White (RAL 9003)
     Sharing cross section: 25 x 60 mm
     Fixing mode: Pre-punched fixing hole 100 mm - Power cable: screwed
     Material: PVC (polyvinyl chloride)
     Manufacturer details: 21 m
     Ambient operating temperature: -25 ... 60 ° C
     Length: 2100 mm
     Height: 60mm
     Width: 25mm

Reference: SCHISM14620P (Schneider-Electric)

Main Features :

    Product line: Altira
    Type of product or component: 1 electrical outlet
    Product presentation: Mechanism
    Configuration of the poles of the socket: 2P + E with eclipses
    Plug standard: French
    Standard description of the plug: With earth contact
    Additional information for socket: Rotoclip / With safety eclipse
    Plate color tint: Red (RAL 3000)

Additional features:

    Product destination: OptiLine 45 installation system
    Earth connection position: Swivel / 45 ° inclined position / 90 ° straight position
    Rated operational current: 16 A - 250 V AC
    Number of modules: 2 modules
    Fixing mode: Clipsable
    Connections - terminals: Screwless terminals for multi-strand twisted rigid cable (s)
    Material: PC for mechanism cover
    Surface treatment: Untreated

Reference: SCHALB45214 (Schneider-Electric)

Product details
Legrand - Double 2P + E 45DEG pre-wired keyed socket IK07 Mosaic 4 modules with automatic terminals - red Reinforced impact resistance: IK07 index
Franco-Belgian standard, 16A, 230V

Mosaic program

With Schneider Electric's Unica + OptiLine 45 combination, you benefit from a large and robust solution that allows you to meet all the technical needs of commercial buildings with a homogeneous finish for power, telephone and data networks close to the workplace. With Unica and OptiLine, everything is thought throughout the installation so that the final result does not suffer from any imperfection. Your work is really highlighted. This white PVC channel has a section of 95x55 mm. This PVC conduit allows a simple fixation by screw to guarantee you a refined result and a flawless finish. The range of OptiLine installation systems are quick solutions to implement for your end-to-end service projects.

Advantages of the product:
     With protective shield
     Easy to install power outlet
     Complete outlet
Main Features
     16 A sockets
     IP 2X mechanisms protected against direct contact - 250 V ~ Delivered with open terminals White finish RAL 9010
     2P + E with protective eclipses - auto terminals
     Terminal capacity: 2 x 2.5 mm2
     Stripping length: 13 mm
Electrical Specifications
     Voltage: 250 V ~
     Intensity: 16 A
     Frequency: 50 Hz
Material characteristics
     Plate: ABS
     Frame: ABS
     Cover: PC
     Color: White RAL 9003
     UV resistance
Mechanical characteristics
     Penetration of solid / liquid bodies: IP 31D
     Impact resistance: IK 04

Characteristics :
- Category: CAT. 6
- Frequency: 250 MHz
- Impedance: 100 ohms
- Conductor: copper-coated aluminum (CCA)
- Shielding: general with aluminum foil
- Wiring standard: compatible with ANSI / TIA 568C.2 - ISO 11801
- Sheath: PVC
- Packaging: individual sachet
- Storage and use temperatures: -20 ° to + 60 ° C
- Not suitable for PoE applications
